■ 180° tipping angle
■ Suitable for boxes with or without bottom deck

■ Clamps exactly on the box edge
■ Box depth adjustable between 850 - 1200 mm
■ Box height adjustable between 850 - 1250 mm
■ Rapid connection system FEM2 and FEM3
■ Standard with two fixed forks
■ Complete with hydraulic hoses and quick connectors
■ Standard equipped with sequence valve (2 hose connection)



Type
Maximum load
Maximum rotation capacity
Frontal extension length
Center of gravity
Maximum box width
Fork distance (center to center)
Weight
Price
K85-1200 2500 kg 1750 kg 440 mm 625 mm 1200 mm 700 mm 700 kg € 8.550,-
K85-1400 2500 kg 1750 kg 440 mm 625 mm 1400 mm 700 mm 725 kg € 8.650,-
K85-1600 2500 kg 1750 kg 440 mm 625 mm 1600 mm 800 mm 745 kg € 8.750,-
K85-1800 2500 kg 1750 kg 440 mm 625 mm 1800 mm 800 mm 765 kg € 8.850,-
K85-2000 2500 kg 1750 kg 440 mm 625 mm 2000 mm 1000 mm 790 kg € 8.950,-
